1013 Bronze Horizontal Check Valve No.9-Screwed

Get a Price/Quote

Product Details:

Material Bronze
Usage Pipe Fitting
Size Various
Pressure High Pressure
Weight Differ as per size Kilograms (kg)
Color Golden
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

1013 Bronze Horizontal Check Valve No.9-Screwed Price And Quantity

Minimum Order Quantity 1 Unit

1013 Bronze Horizontal Check Valve No.9-Screwed Product Specifications

Material Bronze
Usage Pipe Fitting
Weight Differ as per size Kilograms (kg)
Color Golden
Pressure High Pressure
Size Various

1013 Bronze Horizontal Check Valve No.9-Screwed Trade Information

Payment Terms Cash in Advance (CID)
Supply Ability 1000 Unit Per Month
Delivery Time 7 Days
Main Domestic Market All India

Product Description

Salient Features

Screwed Female Ends to IS 554 / BS 21 / ISO 7.
Screwed on Bonnet.
Permits flow in one direction and closes automatically if the flow reverses.
Renewable 13% Cr. Stainless Steel (S.S 410) working parts.
Metal Disc is mushroom shaped with spherical seating surface.
Meant for Horizontal Lines Only.
Disc is guided in Bonnet.
Test Pressure (Hydrostatic) :
Shell : 35 kg/cmg (500 psig)
Working Pressure (Steam) : 10.55 kg/cmg (150 psig)
Maximum Working Temperature : 225C

Materials

P.No.	Name of Part	Material of Construction	Specification	Quantity
1	Body	Bronze	IS 318 Gr. LTB 2	1
2	Body Seat Ring	Stainless Steel	ASTM A276 Type 410	1
3	Disc	Stainless Steel	ASTM A276 Type 410	1
4	Bonnet	Bronze	IS 318 Gr. LTB 2	1

Sizes / Dimensions

Size (Inches)	Size (mm)	A 1.5	B ~	C
1/4	8	60	40	1/4
3/8	10	60	43	3/8
1/2	15	68	48	1/2
3/4	20	84	50	3/4
1	25	95	61	1
1 1/4	32	106	72	1 1/4
1 1/2	40	120	84	1 1/2
2	50	146	93	2
2 1/2	65	180	109	2 1/2
3	80	200	121	3
4	100	248	146	4
